Infrastructure
Auto Insertion
The machine portfolio includes Axial & Radial Eyelet Jumper Machines from Universal & Panasonic.
Manual Insertion
Two Nos. Manual Insertion Line
Automatic conveyorized Insertion Lines of 12mtr each
Automatic Wave soldering machine of Japanese make: Tamura
Automatic output conveyor with Touch Up stations, ICT and customer specific FT Stations
SMT – Completely temperature and humidity control environment
Flexible line with multiple PCBs at one time
Fully automatic free flow process
| S.No. | Machine Name | Make | Model |
|---|---|---|---|
| 1 | Semi Automatic Paste Printer | ||
| 2 | Chip Shooter | Yamaha | YV100 II, YV-100xtg, YG-200, YS12 |
| 3 | Solder Paste Printer | DEK | E by DEK |
| 4 | Reflow | Heller | 1707 |
